WeAct N006 Is a Credit-Card-Sized Jetson Orin NX Carrier for Robots and Drones
WeAct's N006, detailed June 30, 2026, is a 57g NVIDIA Jetson Orin NX carrier board with 40W Super Mode, battery-native power, and stereo cameras — from $110.
A Jetson Brain Small Enough to Fly
Every so often a board lands on my bench that is defined less by raw numbers and more by where it can go — and the WeAct N006, detailed on June 30, 2026, is exactly that kind of board. It is a credit-card-sized carrier for the NVIDIA Jetson Orin NX module, and it is engineered from the ground up for robots and drones rather than the desktop.
The headline is the form factor. The N006 measures just 90 x 60 mm and weighs only 57.8 grams, which is light enough to bolt onto a quadcopter or a small mobile rover without eating into your power budget. It accepts the Jetson Orin NX 8GB or 16GB module and supports up to the module's 40W "Super Mode", so you get serious edge-AI throughput in a package that fits in a shirt pocket.
Built for Battery-Powered Edge AI
What sells me on this as a robotics board is the power design. Instead of expecting a clean wall adapter, the N006 takes 16V to 28V DC over an XT30 connector — 24V recommended — which maps directly onto a 6S battery pack. Anyone who has wired up a drone or a field robot knows that battery-native input saves you an entire stage of buck converters and the heat that comes with them. This is a board that assumes it will live on something that moves.
Storage and expansion are handled by an M.2 Key-M slot for a 2242 NVMe SSD plus an optional M.2 Key-E slot for a Wi-Fi and Bluetooth card. That is the right call: fast local storage for models and logged sensor data, and modular wireless you can add only when the mission needs it.
Vision and I/O That Match the Mission
The N006 carries dual 4-lane MIPI camera interfaces, which is the detail that makes stereo and multi-camera vision practical. Depth perception from a stereo pair is the foundation of obstacle avoidance, and having two native camera lanes means you are not bottlenecked before you even start.
The rest of the single board computer's I/O reads like a robotics wishlist: three USB 3.2 ports (two 10 Gbps Type-A and one Type-C OTG), Gigabit Ethernet, HDMI output, and a rich control header with CAN Bus, dual UART, GPIO, and I2C, plus a dedicated debug UART. CAN Bus in particular is what lets the board talk to motor controllers and flight stacks the way industrial and aerial systems expect.
Why This Board Matters for Makers
Jetson-class compute has always been the dream for hobby robotics, and the friction was rarely the module — it was finding a carrier that was light, battery-friendly, and affordable all at once. At around $110.50 for the board on AliExpress, the N006 hits that intersection cleanly. It is the kind of edge AI hardware that turns a weekend "someday" project — an autonomous rover, a vision-guided drone, a robot arm that actually sees — into something you can wire up now.
For anyone building mobile robotics, the N006 is worth a long look. It is small, it sips from a battery the way an onboard computer should, and it puts a genuinely capable AI accelerator exactly where the action is.
Sources: CNX Software — "WeAct N006 – A compact NVIDIA Jetson Orin NX carrier board designed for robots and UAVs" — June 30, 2026.
