OrangePi O1 Packs 16 TOPS and SATA Onto a 90mm AI Board
The OrangePi O1 pairs a Sophgo BM1688 with a 16 TOPS NPU, up to 16GB RAM, SATA, dual CAN and six camera inputs on a 90x70mm single board computer.
Orange Pi has a new edge AI board aimed squarely at vision and industrial projects. The OrangePi O1, detailed by LinuxGizmos on September 23, 2026, is built around the Sophgo BM1688 and pairs a 16 TOPS neural processing unit with a surprisingly long list of I/O for a 90 x 70mm single board computer, including a full SATA 3.0 port, two CAN buses and inputs for up to six cameras.
- Processor: Sophgo BM1688 with eight Arm Cortex-A53 cores at up to 1.65GHz plus a RISC-V C906 helper core
- AI performance: 16 TOPS INT8, 32 TOPS INT4 and 4.0 TFLOPS FP16/BF16
- Memory and storage: 8GB or 16GB LPDDR4/4X, eMMC up to 128GB, M.2 NVMe and a SATA 3.0 port
- Price: not announced yet
What Can the OrangePi O1's 16 TOPS NPU Run?
The BM1688's tensor processor is the headline. It handles 16 TOPS at INT8 and doubles to 32 TOPS at INT4, and it supports models from Caffe, PyTorch, TensorFlow, ONNX and MXNet. LinuxGizmos lists small language models such as Gemma-2B, Qwen1.5-1.8B, ChatGLM3-6B and Llama2-7B among the supported examples, so a compact on-device assistant is possible alongside the classic computer vision workloads.
Video is where this chip really stretches its legs. The BM1688 can decode 16 streams of 1080p30 H.264 or H.265 video and encode 10, which is the right profile for a small network video recorder with AI detection built in. Two 4-lane MIPI-CSI connectors support up to six camera sensors directly.
OrangePi O1 Ports and Industrial I/O
The connector list reads like an industrial controller squeezed onto an SBC:
- Networking: two Gigabit Ethernet ports, Wi-Fi 6E and Bluetooth 5.3, plus an M.2 B-Key slot for a 4G or 5G modem
- Storage: M.2 M-Key PCIe 3.0 for NVMe, a SATA 3.0 port, microSD and eMMC or SPI flash
- Display: HDMI 2.0 at 4K60 and a 4-lane MIPI-DSI connector
- Industrial: two CAN interfaces, RS485 and a 26-pin GPIO header
- USB and power: two USB 3.0, two USB 2.0 and USB-C power at 20V/3.25A
That SATA port is the unusual one. Most boards in this class stop at NVMe, but a SATA hard drive is still the cheapest way to store days of camera footage, which fits the video-recorder use case neatly. The dual CAN buses point at robotics, vehicles and factory equipment.
How It Compares to Other Orange Pi AI Boards
The O1 sits in an interesting middle ground in the Orange Pi lineup. The Orange Pi 6 chases raw CPU and NPU power with a 12-core CIX chip, while the O1 trades peak CPU speed for video throughput and industrial connectivity. For the full range of options, including Hailo and Jetson add-ons, browse our mini computer coverage.
Who Is the OrangePi O1 For?
This board makes the most sense for makers and integrators building multi-camera systems: a smart NVR, a robot with several vision sensors, or a factory inspection station that needs CAN and RS485. Orange Pi has not announced a price or shipping date yet, so the value question stays open, but the spec sheet already shows a clear purpose. We will update this article when pricing lands.
Sources: LinuxGizmos — September 23, 2026; Orange Pi O1 product page — vendor listing.
