DEBIX T62P-01 Is a Pi-Sized Industrial SBC With Dual TSN Ethernet

A Raspberry Pi Shape With an Industrial Heart

Not every great single-board computer is built for the hobby bench — some are built for the factory floor, and there is real engineering joy in those too. Detailed on June 29, 2026, the DEBIX T62P-01 from Polyhex takes the familiar Raspberry Pi footprint and re-engineers it for rugged, always-on industrial edge deployments.

The Silicon: TI Sitara AM62P

At the core sits the Texas Instruments Sitara AM62P, a SoC with a quad-core Arm Cortex-A53 application processor paired with dual Cortex-R5F real-time cores. That split personality is the whole point: the A53 cores run Linux, Android, or your application logic, while the R5F cores handle the deterministic, hard-real-time tasks that industrial control demands. An integrated Imagination BXS-4-64 GPU handles display and light graphics duties.

The board is compact — roughly 85 by 56 millimeters and just 50 grams — so it slots into the same tight spaces a Pi would, but the surrounding design is all business.

Networking Built for the Factory

The headline feature for me is the networking. The T62P-01 carries dual Gigabit Ethernet ports with TSN — Time-Sensitive Networking — and PoE support. TSN is what lets multiple devices share an Ethernet network while guaranteeing that time-critical messages arrive on a predictable schedule, which is exactly what robotics cells and automated production lines need. Pair that with Wi-Fi 6 and Bluetooth 5.4, dual USB 2.0, and a clever triple-domain UART debug interface over USB-C, and you have a board that talks to almost anything on a plant floor.

Ruggedness and Security That Mean Business

This is where an industrial SBC earns its keep. The T62P-01 offers an optional wide operating temperature range of -40°C to 85°C, so it keeps working in an unheated warehouse in winter or a hot equipment enclosure in summer. On the security side it brings hardware-backed protections — secure boot, Arm TrustZone, and a hardware security module (HSM) — which matter enormously for connected devices that sit unattended in the field for years.

Storage and memory scale to the task too, with 2 to 8 GB of LPDDR4, up to 256 GB of eMMC plus a microSD slot, and a familiar 40-pin header exposing UART, SPI, I2C, CAN, PWM, and GPIO. Software support spans Linux 6.12, Android 16, and FreeRTOS, covering everything from a rich gateway OS to a lean real-time controller.

Why It Is Worth a Look

The T62P-01 is not chasing TOPS or AI benchmarks; it is chasing reliability, determinism, and longevity — the unglamorous virtues that keep machines running. For makers and engineers building robotics, IIoT gateways, or human-machine interfaces, a Pi-sized board with TSN Ethernet, wide-temperature operation, and hardware security is a genuinely useful tool to know about. It is a reminder that the single-board computer world keeps maturing in every direction, including the rugged one.

Sources: CNX Software — "DEBIX T62P-01 Raspberry Pi-like industrial SBC features TI AM62P SoC, dual GbE with TSN" — June 29, 2026.
