Axiomtek's PICO570 Brings Intel Meteor Lake and an 11 TOPS NPU to a 100mm Edge AI SBC

A Tiny Edge AI SBC That Punches Far Above Its Footprint

Axiomtek introduced the PICO570 on April 24, 2026 — a Pico-ITX single board computer built around Intel's Core Ultra (Series 1) Meteor Lake-U processors and engineered specifically for edge AI deployments. At 100 x 72 millimeters, it occupies less surface area than a standard postcard. The capability packed into that footprint is the story.

The headline component is the Intel AI Boost NPU integrated into the Meteor Lake-U processor, delivering 11 TOPS of dedicated neural processing capability without consuming the CPU or GPU resources. For an edge AI SBC running computer vision inference, sensor fusion, or real-time anomaly detection workloads, a dedicated NPU is the difference between a system that can run modern AI models locally and one that cannot.

What the Meteor Lake-U Platform Delivers at the Edge

Axiomtek offers the PICO570 in two standard configurations: the Intel Core Ultra 5 125U and the Core Ultra 7 155U. Both processors combine performance and efficiency cores with Intel Arc integrated graphics and the AI Boost NPU. The 7 155U pushes the upper bound of compute available; the 5 125U offers a more cost-efficient balance for deployments where peak workload pressure is lower.

Memory comes through a single DDR5-5600 SO-DIMM slot supporting up to 64GB. That is a meaningfully high ceiling for an edge SBC and reflects where edge AI inference workloads are heading in 2026 — larger vision models, multi-stream sensor fusion, and on-device fine-tuning all benefit from headroom that previous-generation edge platforms could not provide.

Display and I/O for Real Edge Deployments

The PICO570 delivers HDMI 2.1 output supporting up to 4K@120Hz — substantial display capability for an edge SBC, useful for medical imaging, digital signage, and inspection systems where crisp high-resolution output to a connected display is a requirement rather than a luxury.

Additional I/O includes RS-232/422/485 serial interface for connecting to legacy industrial equipment, two USB 3.0 ports, and a dedicated SMBus connector for system management. The serial port matters because it bridges modern edge AI capability to the substantial installed base of factory and laboratory equipment that still communicates over RS-232 — without external converter modules.

The board operates across a -20°C to +60°C temperature range. That industrial-grade thermal envelope makes the PICO570 suitable for outdoor deployments, factory floors, and other environments where commercial-grade SBCs would not survive a year.

Who the PICO570 Is For

Axiomtek positions the PICO570 explicitly for AI inference nodes, automation controllers, medical imaging systems, and intelligent infrastructure deployments. The combination of an 11 TOPS NPU, modern DDR5 memory bandwidth, 4K@120Hz display output, and industrial I/O is genuinely useful for that target.

For system integrators building edge AI products in 2026, the calculus is straightforward: you want a single board computer that can run modern AI workloads locally, integrate with both new and legacy industrial equipment, and operate reliably in real deployment conditions. The PICO570 covers all three requirements in a Pico-ITX form factor that fits where larger industrial PCs do not.

Software Support

The board ships with Windows 11/10 and Linux support, plus Axiomtek's eAPI3.0 SDK for embedded device management. Linux support is essential for edge AI deployments running containerized inference pipelines, custom ML models, or integration with broader IoT orchestration platforms — and modern Meteor Lake support across mainstream Linux distributions makes this straightforward.

The Edge AI SBC Landscape in 2026

The pattern of edge AI hardware announcements in 2026 is consistent: NPU-equipped processors are migrating into smaller form factors, memory ceilings are rising, and I/O is being designed around real industrial integration rather than consumer use cases. Axiomtek's PICO570 fits that trend cleanly, joining an expanding lineup of single board computers that bring dedicated AI acceleration to deployments where it previously was not economically possible.

For maker and enthusiast builders, this is industrial hardware rather than hobbyist territory — Axiomtek does not publish public pricing and requires a quote request through their product page. But for engineering teams designing intelligent infrastructure at production scale, the PICO570 represents the kind of platform that simply was not available in this footprint a few generations ago.

Sources: CNX Software (April 24, 2026), Axiomtek Product Announcement (April 2026)
